A power supply is an electrical device that supplies electric power to an electrical load.
The main purpose of a power supply is to convert electric current from a source to the correct voltage, current, and frequency to power the load.
Main power supply
Three or single phase supply
Protection
Braking desaturation, overvoltage, overcurrent and overtemperature
Power Supply (PSU) Size 1
| PX1.001.4 | |||
|---|---|---|---|
| Main Power | 220VAc Single Phase | 220Vac Three Phase | 380Vac Three Phase |
| Rated Output Voltage | 310Vdc | 560Vdc | |
| Rated Output Power | 500W | 700W | 1.2kW |
| Peak Output Power | 2kW | 2.8kW | 4.8kW |
| Clamping Voltage Value | 375Vdc | 750Vdc | |
| Recommended Braking Resistor | 70Ω | 100Ω | |
| 100W | 300W | ||
| Auxiliary Power Supply | 24Vdc / 0.2A | ||
| Max. Working Temperature | 40°C | ||
Power Supply (PSU) Size 2
| PX1.010.2 | PX1.015.4 | ||
|---|---|---|---|
| Main Power | 220VAc Single Phase | 220Vac Three Phase | 380Vac Three Phase |
| Rated Output Voltage | 310Vdc | 560Vdc | |
| Rated Output Power | 4kW | 8kW | 15kW |
| Peak Output Power | 5.5kW | 16kW | 30kW |
| Clamping Voltage Value | 375Vdc | 750Vdc | |
| Overload Current | >15A | >27A | >27A |
| Brake Voltage | 400Vdc | 800Vdc | |
| Recommended Braking Resistor | 20Ω | 20Ω | |
| 1000W | 1000W | ||
| Auxiliary Power Supply | 24V , 2A | 24V , 2A | |
